FLAMEX FRLS (Flame Retardant Low Smoke)
Description
India’s 1st REACH and RoHS Compliant Cable | Flame Retardant Low Smoke Low Halogen.
REACH,CE,ROHS and CPR Compliant.
Anti-Rodent, Anti-Termite
100% Electrolytic Copper
More than 101% Conductivity
Application
Suitable for use in conduit and for fixed, protected installation particularly suitable for wiring in fire and explosion prone areas, chemical factories, densely wired areas, public buildings, schools, hospitals, commercial complexes, theatres, etc.
Technical Data
Approvals : IS 694 marked, FIA/TAC.
Voltage Grade : Up to and including 1100V
Insulation : Specially formulated flame retardant low smoke low halogen compound to restrict the spread of flames in fire situation.The smoke emitted by the burning cable is considerably low compared to traditional cables. This ensures improved visibility for evacuation of trapped victims and facilitates fire fighting operation.
Insulation Conformity : IS 5831 Type A/D FR-LSH 70°C
Colours : Entire cable has white base and a double strip of Green, Black, Red, Yellow, Blue, Grey, running along the cable length.
Marking : The cables are printed with the marking of 'FLAMEX FR-LSH’.
Packing : 90 mtr. coils packed in protective cartons.
Cable Design Parameters
Kindly complete the part numbers for these cables by adding the suffix (in place of ‘xx’) for the colour required: 01 – green, 02 – black, 03 – red, 04 – blue, 05 – yellow, 06 – grey.
| Part Number | Nominal Cross Sectional Area (Sq. mm) | Nominal Insulation Thickness (mm) | Number *Nominal Dia. of Strands | Approx. Overall Diameter (mm) | Max. DC Conductor Resistance at 20°C (Ω/km) | Current Rating (Amps) | |
|---|---|---|---|---|---|---|---|
| Casing | Concealed | ||||||
| 01020101xx50 | 1 | 0.7 | 14/0.3 | 2.7 | 18.1 | 14 | 13 |
| 01020102xx50 | 1.5 | 0.7 | 22/0.3 | 3.0 | 12.1 | 18 | 16 |
| 01020103xx50 | 2.5 | 0.8 | 36/0.3 | 3.7 | 7.41 | 24 | 20 |
| 01020104xx50 | 4** | 0.8 | 56/0.3 | 4.1 | 4.95 | 30 | 26 |
*Conductor as per IS 8130.
**Insulation Type D as per IS 5831
Properties
| Test | Test Method | Values |
|---|---|---|
| Limited Oxygen Index | IS 10810 P – 58 | > 29% |
| Limited Temperature Index | IS 10810 P – 64 | > 250OC |
| Smoke Density (Light Absorption) | IS 13360 P – 6/Sec 9 | < 60% |
| Acid Gas Generation | IS 10810 P – 59 | < 20% |
