Jin Power Solution

Product Code	LZCOB07	LZCOB18	LZCOB35
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	7w±5%	18w±5%	35w±5%
Photometric Data
Rated Luminous Flux	735 Lm	1890 Lm	3675 Lm
LED Light Source	COB
Color Rendering Index (CRI)	≥80
Beam Angle	24°
Luminous Efficiency	110 Lm/W
Color Temperature (CCT)	3000K (WW), 4000k (NWH), 6000K (WH)
Working Temperature	–20°c to + 40°c
Luminaire Data
Dimension	Ø: 89mm, H: 55mm	Ø: 125mm, H: 75mm	Ø: 155mm, H: 120mm
Ceiling Cutout	Ø: 80mm	Ø: 117mm	Ø: 148mm
Rated Life	50000 Hours
IP Rating	IP20
Luminaire Body & Finish	Die-cast Al. Body with high efficiency Aluminium Reflect or optics

Product Code	LZCOB50	LZCOB50SQ
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	50w±5%	50w±5%
Photometric Data
Rated Luminous Flux	5250 Lm	5250 Lm
LED Light Source	COB
Color Rendering Index (CRI)	≥80
Beam Angle	24°
Luminous Efficiency	110 Lm/W
Color Temperature (CCT)	3000K (WW), 4000k (NWH), 6000K (WH)
Working Temperature	–20°c to + 40°c
Luminaire Data
Dimension	Ø: 200mm, H: 150mm	L: 240mm, W: 145mm, H:100
Ceiling Cutout	Ø: 180mm	L:210, W:120mm
Rated Life	50000 Hours
IP Rating	IP20
Luminaire Body & Finish	Die-cast Al. Body with high efficiency Aluminium Reflect or optics
