Product Code	LST15	LST24	LST36	LST48	LST60
Electrical Data
Input Voltage Range	AC 150-300 V
Power factor	≥0.95
Power Consumption	15 w±5%	24 w±5%	36 w±5%	48 w±5%	60 w±5%
Surge Voltage	6KV
Photometric Data
Rated Luminous Flux	1500 Lm	2400 Lm	3600 Lm	4800 Lm	6000 Lm
LED Light Source	SMD
Color Rendering Index (CRI)	≥80
Beam Angle	120°
Luminous Efficiency	100 Lm/W
Color Temperature (CCT)	6000K (WH), (3000K (WW)-On Request)
Working Temperature	0°c to + 55°c
Luminaire Data
Dimension	L: 350mm, W: 95mm, H:65, Pipe Inner Dia: 40mm	L: 350mm, W: 95mm, H:65, Pipe Inner Dia: 40mm	L: 385mm, W: 145mm, H:60, Pipe Inner Dia: 40mm	L: 405mm, W: 195mm, H:70, Pipe Inner Dia: 52mm	L: 405mm, W: 195mm, H:70, Pipe Inner Dia: 52mm
Rated Life	50000 Hours
IP Rating	IP65
Luminaire Body & Finish	Die cast aluminium body & Toughened Glass

Product Code	LST72	LST90	LST120	LST160
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	72 w±10%	90 w±10%	120 w±10%	160 w±10%
Surge Voltage	6KV
Photometric Data
Rated Luminous Flux	7200 Lm	9000 Lm	12000 Lm	16000 Lm
LED Light Source	SMD
Color Rendering Index (CRI)	≥80
Beam Angle	120°
Luminous Efficiency	100 Lm/W
Color Temperature (CCT)	6000K (WH), (3000K (WW) - on request)
Working Temperature	0°c to + 55°c
Luminaire Data
Dimension	L:430mm, W:205mm, H-75, Pipe Inner Dia: 52mm	L:510mm, W:260mm, H-75, Pipe Inner Dia: 52mm	L:510mm, W:260mm, H-75, Pipe Inner Dia: 52mm	L:510mm, W:260mm, H-75, Pipe Inner Dia: 52mm
Rated Life	50000 Hours
IP Rating	IP65
Luminaire Body & Finish	Die Cast Aluminium Body & Toughened Glass
