LED LEADS LIGHTING TO PREEMINENT LEVELS

Lighting can provide you with intense pleasure of designs through products in ON and OFF conditions. It may be surprising statement, but true with our new range of panels. Our latest range of premium panels give value addition to the beautiful interiors with its presence itself.

The range is convenient, compact and more aesthetically designed with maximum light output.

Utilize our artistic range of new premium panels along with your creativity to bring the best out for all.

Product Code	LIPR03	LIPR06	LIPR12	LIPR15	LIPR18
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	3 w±5%	6 w±5%	12 w±5%	15 w±5%	18 w±5%
Surge Voltage	2.5kv
Photometric Data
Rated Luminous Flux	285 Lm	570 Lm	1140 Lm	1425 Lm	1710 Lm
LED Light Source	SMD
Color Rendering Index (CRI)	≥80
Beam Angle	120°
Luminous Efficiency	90-95 Lm/W
Color Temperature (CCT)	3000K (WW), 4000k (NWH), 6000K (WH)
Working Temperature	0°c to + 50°c
Luminaire Data
Dimension in mm	Ø:82mm, H:36mm	Ø:120mm, H:29mm	Ø:170mm, H:29mm	Ø:170mm, H:29mm	Ø:225mm, H:29mm
Ceiling Cutout in mm	Ø:65mm	Ø:105mm	Ø:155mm	Ø:155mm	Ø:210mm
Rated Life	40000 Hours
IP Rating	IP40
Luminaire Body & Finish	ABS Plastic with PC Diffuser

Product Code	LIPS03	LIPS06	LIPS12	LIPS15	LIPS18
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	3 w±5%	6 w±5%	12 w±5%	15 w±5%	18 w±5%
Surge Voltage	2.5kv
Photometric Data
Rated Luminous Flux	285 Lm	570 Lm	1140 Lm	1425 Lm	1710 Lm
LED Light Source	SMD
Color Rendering Index (CRI)	≥80
Beam Angle	120°
Luminous Efficiency	90-95 Lm/W
Color Temperature (CCT)	3000K (WW), 4000k (NWH), 6000K (WH)
Working Temperature	0°c to + 50°c
Luminaire Data
Dimension in mm	L:82, W:82, H:29	L:120, W:120, H:29	L:170, W:170, H:29	L:170, W:170, H:29	L:225, W:225, H:29
Ceiling Cutout in mm	L:65, W:65	L:105, W:105	L:155, W:155	L:155, W:155	L:210, W:210
Rated Life	40000 Hours
IP Rating	IP40
Luminaire Body & Finish	ABS Plastic with PC Diffuser
