Jin Power Solution

Product Code	LNPR03	LNPR06	LNPR09
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	3 w±5%	6 w±5%	9 w±5%
Surge Voltage	2.5kv
Photometric Data
Rated Luminous Flux	300 Lm	600 Lm	900 Lm
LED Light Source	SMD
Color Rendering Index (CRI)	≥80
Beam Angle	120°
Luminous Efficacy	95-100 Lm/W
Color Temperature (CCT)	3000K (WW), 4000K (NWH), 6000K (WH)
Working Temperature	0°c to + 50°c
Luminaire Data
Dimension	Ø:90mm, H:20mm	Ø:120mm, H:20mm	Ø:145mm, H:20mm
Ceiling Cutout	Ø:73mm	Ø:102mm	Ø:125mm
Rated Life	40000 Hours
IP Rating	IP40
Luminaire Body & Finish	Aluminium body with PC Diffuser

Product Code	LNPR12	LNPR15	LNPR18	LNPR30
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	12 w±5%	15 w±5%	18 w±5%	30 w±5%
Surge Voltage	2.5kv
Photometric Data
Rated Luminous Flux	1200 Lm	1500 Lm	1800 Lm	3000 Lm
LED Light Source	SMD
Color Rendering Index (CRI)	≥80
Beam Angle	120°
Luminous Efficiency	95-100 Lm/W
Color Temperature (CCT)	3000K (WW), 4000K (NWH), 6000K (WH)
Working Temperature	0°c to + 50°c
Luminaire Data
Dimension	Ø:173mm, H:20mm	Ø:193mm, H:20mm	Ø:224mm, H:20mm	Ø:301mm, H:20mm
Ceiling Cutout	Ø:153mm	Ø:175mm	Ø:203mm	Ø:272mm
Rated Life	40000 Hours
IP Rating	IP40
Luminaire Body & Finish	Aluminium body with PC Diffuser

JV Lukar
