Product Code	LDRJB03	LDR05	LDR07	LDR15	LDR20	LDR4405	LDR4412
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	3 w±5%	5 w±5%	7 w±5%	15 w±5%	20 w±5%	5 w±5%	12w±5%
Photometric Data
Rated Luminous Flux	300 Lm	500 Lm	700 Lm	1500 Lm	2000 Lm	400Lm	960Lm
LED Light Source	SMD
Color Rendering Index (CRI)	≥80
Beam Angle	120°
Luminous Efficiency	90-100Lm/W						≥80Lm/W
Color Temperature (CCT)	WH,WW,R,G,B	3000K (WW), 4000k (NWH), 6000K (WH)
Working Temperature	0°c to + 50°c
Luminaire Data
Dimension	Ø:65mm, H:32mm	Ø:110mm, H:50mm	Ø:120mm, H:53mm	Ø:188mm, H:72mm	Ø:188mm, H:72mm	Ø:88mm, H:26mm	Ø:145mm, H:27mm
Ceiling Cutout	Ø:38mm	Ø:95mm	Ø:92mm	Ø:150mm	Ø:150mm	Ø:75mm	Ø:130mm
Rated Life	40000 Hours
IP Rating	IP40						IP54
Luminaire Body & Finish	Aluminium body with reflector	Aluminium body with PC Diffuser

Product Code	LDS07	LDS15	LDS22	LKM2240	LKM2245	LKMSRS45
Electrical Data
Input Voltage Range	AC 100-300 V
Power factor	≥0.95
Power Consumption	7 w±5%	15 w±5%	22 w±5%	36/40W w±5%	45w w±5%	45w w±5%
Photometric Data
Rated Luminous Flux	770 Lm	1650 Lm	2420 Lm	3400/3800 Lm	4500 Lm	4500 Lm
LED Light Source	SMD
Color Rendering Index (CRI)	≥80
Beam Angle	120°
Luminous Efficiency	100-110 Lm/W			95-100 Lm/W
Color Temperature (CCT)	3000K (WW), 4000K (NWH), 6000K (WH)			6000K (WH)	3000K (WW),6000K (WH)
Working Temperature	0°c to + 50°c
Luminaire Data
Dimension	L:116mm, W:116mm, H:36mm	L:166mm, W:166mm, H:36mm	L:220mm, W:220mm, H:36mm	L:595mm, W:595mm, H:35mm	L:595mm, W:595mm, H:35mm	L:595mm, W:595mm, H:35mm
Ceiling Cutout	L:100mm,W:100mm	L:150mm, W:150mm	L:205mm, W:205mm	L:570mm, W:570mm	L:570mm, W:570mm	Surface Mount
Rated Life	40000 Hours
IP Rating	IP40
Luminaire Body & Finish	ABS plastic with PC Diffuser			Aluminium body with PC Diffuser
