Polycab Automatic Changeover with Current Limiter (ACCL) is a fully automatic high precision micro-controller based system designed to provide power to critical loads where a backup generator is located, so that the generator may provide temporary electrical power if utility supply fails. It’s ideally suited for conservation of energy of standby Generators used in multistoried apartments, commercial complexes, industrial establishments, etc through limiting the current..
IP20 Protection and environment-friendly FR body material.
Power consumed is less then 0.2VA during Mains supply & 15VA during generator operation
Unique Contractor based technology. Break before make changeover contacts with higher air gap.
25,000 Electrical Operations
Auto Reset Facility
Utilisation Category AC22A (IEC 60947-3) & AC32A (IEC 60947-6)
Conditional short circuit current capacity 5kA
Can be fitted with Polycab MCB range on DIN Rail
Alert on overload at Generator side by LED and BEEP.
